Descriptions:
Range:0.003~ 20G
Accuracy:0.001G Dimensions: 144X84.5X51MM LCD liquid crystal display (blue backlight) size: 375X15.5MM Battery: 2X'AAA'(not included) Low battery alarm 'LO' Weighing pan size: diameter 32MM (with stainless steel weighing disc) Function buttons and instructions for use 1.ON/OFF (switch key) Install the 2 AAA batteries into the cover battery door in the direction specified by the battery compartment. Place the scale body on a stable tabletop, keep the level bubble in the center of the black circle, press this button to display “88888” and turn it back to zero when the power is turned off. At this time, the loaded item can be weighed on the weighing pan, weighing state. Press this button to turn off the phone. Weigh the environment. If there is wind, please put down the windshield measurement. 2. UNIT (unit conversion key) Press this button to select different weighing units: G, OZ, GN, CT, T, OZT, Press and hold the unit conversion button for 4 seconds to light all the units, the OZ unit will flash, press the tare button PCS to select to hide or display, and press the unit conversion button to shift another unit. (This function is reserved for the customer to select the practical unit. Choose.) Exit long press for 4 seconds to return to normal mode, G units can not be hidden. 3.TARE Press this button to force zero to zero when the power is turned on. 4. PCS (counting function) After turning on the machine, the number of points is 25 or 50, 75, 100. Any sample value is placed on the weighing pan. At this time, the LCD will display a default value (such as P 25) by pressing the counting button. Press the key to select (25, 50.75, 100) the value of the sample value of the number of points, and then press the count key to confirm. At this time, the LCD displays the value of the PCS + sample value (such as 50). At this time, the item to be counted can be loaded on the weighing pan. . Calibration function 0.00 is displayed when the power is turned on, and 0-(zero point) is displayed after pressing the power button for 4 seconds. After waiting for 1 second, the weight value to be calibrated is displayed. The maximum weighing of the scale is 30G (displaying 30.000 flashing). Load the 30G weight on the weighing pan, display PASS after stabilization, and the calibration is completed. (This product is delivered randomly with 20g weight, reduced by unit count key to 20.000, loaded with 20G weight to display PASS and calibration completed.) When the calibration weight value flashes, press the unit conversion key to add value, press the count key to decrease value, according to 10G amplitude addition and subtraction can choose the appropriate weight value to calibrate 10G-30G, and remember the last set calibration value after shutdown. Automatic shutdown time setting Press and hold the 4 seconds ON/OFF button to turn off the 88888 button until the display F1-1 press the UNIT unit button to select the value of 0-5 respectively. 0=Do not shut down 1-5 respectively, indicating that there is no operation state 1 to 5 Divided into automatic shutdown time. Choose the right shutdown time according to your needs to save battery life. After the selection is completed, press the power button to return to zero to weigh. Package Includes:
1 x Digital Scale
1 x 20G Weight 1 x Tweezers 1 x Stainless Steel Weighing Disc
Details Pictures:
|
