5.43kWh SVOLT A-GRADE Lithium BATTERY 51.2V 106AH (Square)

SVOLT 5.43kWh 51.2V 106Ah A-Grade LiFePO4 Battery High-Performance Energy Storage

Description:

The SVOLT 5.43kWh 51.2V 106Ah Lithium Iron Phosphate (LiFePO4) Battery is a high-efficiency energy storage solution designed for residential, commercial, and industrial applications. Manufactured with A-Grade lithium cells, this battery delivers superior performance, reliability, and a long lifespan. Ideal for solar energy storage, electric vehicles, medical equipment, telecommunications, and uninterruptible power supplies (UPS), it ensures consistent and maintenance-free operation.

Key Features:

• A-Grade LiFePO4 Cell Technology: Provides high efficiency, durability, and long cycle life.
• Long-Lasting Performance:
  • Over 4,000 charge cycles at 80% Depth of Discharge (DoD).
  • 99.5% round-trip efficiency for optimized energy storage.
• Integrated Battery Management System (BMS):
  • Built-in safety protections against overcharging, over-discharging, and overheating.
  • Supports RS485 and CAN communication for system integration.
• Scalable Energy Storage:
  • Supports up to 16 batteries in parallel for expanded energy capacity.
  • Series connections are not supported.
• High Power Output:
  • Max Continuous Charge/Discharge Current: 100A
  • Peak Discharge Current: 120A (5s)
• Temperature Resilience:
  • Discharge Range: -20°C to 65°C
  • Charge Range: 0°C to 45°C
  • Storage Temperature: -10°C to 30°C
• Durable & Safe Construction:
  • Metal case for enhanced durability and protection.
  • IP-rated protection for secure energy storage.

Technical Specifications:

• Battery Type: Lithium Iron Phosphate (LiFePO4)
• Nominal Voltage: 51.2V
• Nominal Capacity: 106Ah
• Energy Density: 5.43kWh
• Terminal Type: M6 (Torque: 8.5NM)
• Voltage Window: 44.8V - 57.6V
• Max Charge Voltage: 58.4V ± 0.20V
• Recommended Charge Current: 50A
• Max Continuous Discharge Current: 100A
• Peak Discharge Current: 120A (5s)
• Cycle Life: >4,000 cycles at 80% DoD
• Communication Ports: RS485, CAN, Dryport
• BMS Safety Protections:
  • Primary & Secondary Overcharge Protection
  • Primary & Secondary Over-Discharge Protection
  • Temperature Protection (Auto Recovery at 85°C)
• Dimensions & Weight:
  • Weight: Approx. 50kg
  • Box Dimensions: 550mm x 520mm x 220mm

What's in the Box?

• 1 x SVOLT 5.43kWh 51.2V 106Ah Lithium Battery
• 1 x Red (Positive) Battery Cable
• 1 x Black (Negative) Battery Cable
• 1 x Communication Cable
• 1 x User Manual

Warranty & Installation Requirements:

• 5-Year Warranty included.
• Installation must be performed by a qualified electrical wireman or master electrician registered with the Department of Labour.
• A valid Certificate of Compliance (COC) must be issued after installation, ensuring adherence to SANS 10142 standards.
• Warranty claims require installation photos, a valid COC, and proof of installation by a certified professional. Failure to comply may result in a voided warranty.
