Ethernet Ports WAN: 1 x RJ45 for 10/100BaseT
LAN: 4 x RJ45 for 10/100BaseT
Support Ethernet and 802.3 with max.
10/100Mbps and auto cross-over function (MDI-X)
Antenna Support:
1 x Internal inverted-F PCB antenna
1 x External dipole antenna with reverse-SMA antenna
BroadRange Technology The WL550GE adopts Broadcom's new BroadRange
technology increasing the signal coverage range by 300%.
(BroadRange support is required on client/adapter side
such as WL138GE, WL169GE and WL100GE)
125* High Speed Mode With "Afterburner" technology, WL-550GE can boost wireless
transfer speeds by 35% compared with standard 802.11g speeds
Afterburner support is also required on client/adapter side.
Reset button Push for 5 seconds to restore factory setting
Management Smart Wizard browser-based administration
Remote management
DHCP server, WAN DHCP client
Upgrades via web browser
Firmware restoration
Radio Power Control
Firewall 2 true firewalls NAT and SPI to filter out attacks from
the Internet.
Data Rate 802.11g: 6, 9, 12, 18, 24, 36, 48, 54M, 125Mbps
*Supports 802.11g 125 high-speed mode
Output Power 11 ~ 20 dBm (at normal temp. range)
Encryption 64/128-bit WEP
TKIP, AES, WPA2, WPA-PSK,
Authentication MAC address, 802.1x
DC Power Adapter AC Input: 100V~240V(50~60HZ)
DC Output: 5V with max. 2 A current
Size 185mm(L)x 205mm(W)x 36mm(H)
excluding one external antennas
Weight 500g excluding power supply
THIS ITEM DOES NOT HAVE A POWER ADAPTER
