GSM Wireless Home Smart Relay Switch

Features:

1. Can be operated from anywhere, no distance limitation.
2. Up to 200 authorized phone numbers. the 1st ~3rd user number scan receive SMS, and the 4th ~6th user number scan receive call while alarm occurrence.1~200 authorized phone numbers can call T200 to turn on/off the Relay0 free of charge
3. One Temperature & Humidity sensor input, temperature measure range: -40~80°C,accuracy:0.5°C. Humidity measure range: 0-99%RH, accuracy:3%.
4. External AC/DC Power status monitoring, AC/DC Power On/OFF will send SMS and call to 6 preset mobile phone immediately.
5. Timer ReportCan setup every x hours automatically send its status/value to 6 preset mobile phone immediately.
6. Support remotely read historic data via SMS.
7. An automation system. When the temperature, humidity, power alarm or normal, it can link to Realy1 to action.
8. A siren output. when Alarm occurrence, it will output for 30 seconds.
9. Rechargeable Backup Battery inside can last 6hour.
10. Secure - Using caller ID and password for identification, unknown callers are ignored.
11. Programmable by SMS Commands with password protection.
12. Based on GSM Network, applied to many applications. (temperature, humidity, power status, solar panel, dc voltage).

Specification:

Rated Voltage: DC 9V~24V/1A

Working temperature: -10～+60

Storage temperature: -20～+60

Relative humidity: 10-90%, No condensation

GSM: 850/900/1800/1900MHz

Communication protocol: GSM PHASE 2/2+ (include data service)

Related Voltage of the Output Relay: 3A/240V AC

SIM Card: Nano type, 3V

Antenna: 50 SMA

Wired Switch: Supports

Wired Zones: 2

Dimension: 96.5 x 72 x 59mm

Package Contents:

1 x GSM remote controller
