GeForce RTX 3060 Ti GeForce RTX 3060
GPU Engine Specs: NVIDIA CUDA® Cores 4864 3584
Boost Clock (GHz) 1.67 1.78
Base Clock (GHz) 1.41 1.32
Memory Specs: Standard Memory Config 8 GB GDDR6 / 8 GB GDDR6X 12 GB GDDR6 / 8 GB GDDR6
Memory Interface Width 256-bit 192-bit / 128-bit
Technology Support: Ray Tracing Cores 2nd Generation 2nd Generation
Tensor Cores 3rd Generation 3rd Generation
NVIDIA Architecture Ampere Ampere
Microsoft DirectX® 12 Ultimate Yes Yes
NVIDIA DLSS Yes Yes
NVIDIA Reflex Yes Yes
NVIDIA Broadcast Yes Yes
PCI Express Gen 4 Yes Yes
Resizable BAR Yes Yes
NVIDIA® GeForce Experience Yes Yes
NVIDIA Ansel Yes Yes
NVIDIA FreeStyle Yes Yes
NVIDIA ShadowPlay Yes Yes
NVIDIA Highlights Yes Yes
NVIDIA G-SYNC® Yes Yes
Game Ready Drivers Yes Yes
NVIDIA Studio Drivers Yes Yes
NVIDIA Omniverse Yes Yes
NVIDIA GPU Boost Yes Yes
NVIDIA NVLink (SLI-Ready) - -
Vulkan RT API, OpenGL 4.6 Yes Yes
NVIDIA Encoder 7th Generation 7th Generation
NVIDIA Decoder 5th Generation 5th Generation
CUDA Capability 8.6 8.6
VR Ready Yes Yes
Display Support: Maximum Digital Resolution (1) 7680x4320 7680x4320
Standard Display Connectors HDMI(2), 3x DisplayPort(3) HDMI(2), 3x DisplayPort(3)
Multi Monitor 4 4
HDCP 2.3 2.3
Card Dimensions: Length 9.5" (242 mm)
Width 4.4" (112 mm)
Slot 2-Slot
Thermal and Power Specs: Maximum GPU Temperature (in C) 93 93
Graphics Card Power (W) 200 170
Required System Power (W) (4) 600 550
Supplementary Power Connectors 1x PCIe 8-pin
(adapter to 1x 12-pin included)
NB: PRODUCT NOT IN ORIGINAL BOX
