OBD2 ELM327 V2.1 Bluetooth Adapter Automotive Diagnostic Tool

Product Introduction:

Please note:

- This product is only suitable for gasoline vehicles. It is not suitable for diesel vehicles.

- It is suitable for almost all brands of gasoline vehicles.

- ELM327 SW: V2.1, HW: V1.5. Only 7 obd2 protocols are supported

- It does not support IOS, please note.

Description:

- Software version: V2.1, Hardware version: V2.1

- Suitable for all vehicles that meet the OBD-II standard

- Applicable APP (can scan the QR code to download)

- Window: ScanMaster-ELM, ScanTool.net, PCMSCAN ELM, etc.

- IOS: Auto Doctor, Mini OBDII

- Android: Torque, DashCommand, OBD Car Doctor, Auto Doctor, Mini OBD, EOBD, etc.

- ELM327 password: 1234 or 0000. WIFI version ELM327 has no password.

- BT ELM327--------Android phone works

- WIFI ELM327------IOS and Android phone works

- Samsung and Xiaomi phones have unstable connections and will block strange connectors, thank you for your understanding!

ELM 327 V2.1 Specifications:

- Model: ELM327 OBD2 Bluetooth/WIFI

- Type: Code Reader and Scan Tool

- Output Protocol: Bluetooth/WIFI

- Voltage: 12V

- Current: 45mA

- Wave Frequency: 38400Hz

- Applicable Range: 5-10m / 16.4-32.8ft

ELM327 2.1 OBD2 Bluetooth supports 7 OBDII protocol types as follows:

- Vehicle Coverage: Applicable to all OBD2 vehicles.

- SO9141-3 (5 baud initialization, 10.4K baud)

- ISO14230-4 (5 baud initialization, 10.4 K baud)

- ISO15765-4 CAN (11 bit ID, 500 K baud)

- ISO15765-4 CAN (29 bit ID, 500 K baud)

- ISO15765-4 CAN (11 bit ID, 250 K baud)

- ISO15765-4 CAN (29 bit ID, 250 K baud)

- KWP2000 5 10.4 K baud
